PAGE 5
BAB 7/01
A. BUTT HINGE, CONTINUOUS HINGE, AND CENTER PIVOTS
(CON’T)
2. 4" OR 4 1/2" HEADER/T’BAR INSTALLATION STEPS
SECTION II HEADER/TRANSOM BAR
INSTALLATION
(CON’T)
A.
ATTACH THE SHEAR BLOCK (K173) TO THE HINGE/PIVOT JAMB(S) WITH
THREE #8-15X1 3/4" PL-PH-SMS {S100}.
B.
REPEAT STEP 1 ON THE LOCK JAMB(S).
C.
ATTACH THE DORMA "F" CLIP TO THE HINGE/PIVOT JAMB(S) WITH TWO
#10-32x5/8" PH-MS (C).
D.
COAT BOTH ENDS OF THE HEADER/TRANSOM BAR WITH BUTYL TYPE
SEALANT AND INSTALL IT OVER THE SHEAR BLOCKS.
E.
FASTEN THE HEADER/TRANSOM BAR AT THE HINGE/PIVOT JAMB(S) TO THE
SHEAR BLOCK WITH TWO #12-11 X 1/2" PL-RH-SMS 18-8 A {STB9}.
F.
REPEAT STEP E. ON THE LOCK JAMB(S).
