steps on pages 36 and 37.
FIG. # 44
equal glass bite all around.
E) Install the exterior gasket.
C) Stretch the antiwalk block as shown
in Fig. 44 below, and insert it from the
exterior at midlite and deep pocket
D) Recenter the glass unit to maintain
side only.
ANTIWALK BLOCK
HN52
C - ANTIWALK BLOCK INSTALLATION
STEP 1) ANTIWALK BLOCK INSTALLATION
A) Install the interior gasket following the
steps on page 34.
B) Position the glass as described in the
SECTION V GLAZING
406 STOREFRONT DPS 12/2002
PAGE 38
