EFCO 406 (T) Series - Manual (Page 39)

SECTION V GLAZING
1/4 points of the D.L.O. Then lower the glass onto the setting blocks.
F) Snap on the removable glass stop and install the exterior glazing gasket.
E) Insert the setting blocks under the glass at the proper locations, typically
D) Lift the glass into the head member's glazing pocket.
E
F
Fig. # 43
D
1G83
9357
9359
STEP 2) GLASS INSTALLATION
B - GLASS INSTALLATION
406 STOREFRONT CSJ 11/2007
PAGE 37
LB78 full length/FV16 3" clip
FV16 3" clip
