Page 18: Fig. # 14, Fig. # 13

D - SNAP-IN GLAZING POCKET &

SECTION III FABRICATION

SCREW APPLIED GLAZING

1) SNAP-IN GLAZING POCKET END PREP

BACK WALL OF PART AS SHOWN.

NOTCH THROUGH GLAZING TRACKS AND

2) SCREW APPLIED GLAZING END PREPS

#9250

THIS END

TO TRANSOM BAR

.188

.358

VERTICAL D.L.O. - 1/32"

CUT LENGTH =

1.781

.188

NOTE:

.358

THIS END

TO TRANSOM BAR

.358

VERTICAL D.L.O. - 1/32"

CUT LENGTHS =

Fig. # 14

1.780

#9133

Fig. # 13

.188

.173

#8403

PAGE 16

DPS 12/2002

406 STOREFRONT
