Fig. # 18 – EFCO 406 (T) Series User Manual

Page 22

Fig. # 18

#8402 DOOR JAMB

FACTORY PREP SHOWN

#9954/#9955 DOOR STOP

OPPOSITE A C.O.C.

THIS ASSEMBLY IS

AT A SINGLE DOOR.

#K978

#8400

A - DOOR FRAME ASSEMBLY

SECTION IV ASSEMBLY & INSTALLATION

FOR TRANSOM D.L.O. OVER 48" USE #9250 AND #9133

APPLIED GLAZING AT JAMB APPLIED STOPS RUN THROUGH
AT TRANSOM BAR GLAZING STOPS.

CUT LENGTH = VERTICAL D.LO. - 1/32".

CAVITY

SEALANT IN

#K9250 / #9133

See page 16 for end prep.

#K977

EXPLODED VIEW

BEFORE ASSEMBLY

ALL HORIZONTAL ENDS

APPLY SEALANT TO

#9359

(CONT.)

406 STOREFRONT

DPS 12/2002

PAGE 20
