EFCO CORPORATION 6/2012 PART NO. Y557 20
Series 5500 Advanced & Alternate Installation Instructions
STEP #1 SIDE STACK PRE-ASSEMBLED FRAMES
Frames can be partially assembled off-site and moved to the jobsite. Then, groups of frames may be
snapped together, allowing them to be set into the opening at one time. The size of the group of
frames to be installed is limited by the field’s handling capacity due to the weight and size of the
assemblies.
PRE-ASSEMBLED
FRAMES
See Section III of the Standard
Installation Instructions , step 4 for
special sealant note at horizontals.
Section V: PUNCHED OPENING & RIBBON WINDOWS
(Frame Opening & Frame Sealing)
