Dynojet Spring Applied Air Release (SAAR) Brake Assembly User Manual
Page 3

Spring Applied Air Release (SAAR) Brake Assembly Installation
i
T
ABLE
OF
C
ONTENTS
Spring Applied Air Release (SAAR)
Brake Assembly Installation
Introduction
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
The Hydraulic Brake Assembly
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Preparing to Remove the Hydraulic Brake . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Removing the Hydraulic Brake Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installing the SAAR Brake Assembly
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing the Brake Weldment and Brake Shoes . . . . . . . . . . . . . . . . . . . . . 12
Installing the Air Can Mount and Tube . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing the Air Can . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Connecting to the Breakout Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting to the Shop Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Fastening the Air Can . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Powering up and Testing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Four Wheel Drive Dynos
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Upgrading the Moveable 224 Dyno . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Connecting the Movement Board and Shop Air . . . . . . . . . . . . . . . . . . . . . 20
