S P R I N G A P P L I E D A I R R E L E A S E ( S A A R ) B R A K E A S S E M B L Y I N S T A L L A T I O N
The Hydraulic Brake Assembly
Version 1
Spring Applied Air Release (SAAR) Brake Assembly Installation
11
8
The hydraulic brake assembly should now be completely free. Remove it from the
dyno.
9
Extract the brake clevis pins from the square recesses and set them aside.
Note: You will reuse the brake shoes and the two clevis pins. The other parts can
be appropriately discarded.
.
Figure 10: Remove the Hydraulic Brake Assembly
BR018
remove hydraulic brake
assembly
