Spring Applied Air Release (SAAR) Brake Assembly Installation
S P R I N G A P P L I E D A I R R E L E A S E ( S A A R ) B R A K E A S S E M B L Y I N S T A L L A T I O N
Installing the SAAR Brake Assembly
14
I
NSTALLING
THE
A
IR
C
AN
M
OUNT
AND
T
UBE
1
Install the air can mount using the four 3/8"-16 x 1-1/2" flange bolts provided
Figure 14: Attach the Air Can Mount to the Dyno
BR027
four 3/8"-16 x 1-1/2"
flange bolts
air can assembly
air can mount
