Salter Brecknell 7840 - Manual (Page 24)

Model 7800 Family Weight Classifiers User’s Manual 24
NOTES:
(1) The output print formats for AUTO-1, AUTO-
2 and manual print operation are defined in
Table 3 and set in the PRTOUT setting of the
CONF menu.
(2) The TEST button will retain its test function
(i.e. will not be redefined as a SEND key)
when displayed weight is at zero as indicated
when the Center-Zero indicator is on.
3) While in AUTO-1, AUTO-2, or manual print
modes, scale will not respond to external
serial commands.
The Calibration (CAL) Mode menu lets you
calibrate your scale. The items in the calibration
menu are as follows:
POUNDS/KILOGRAMS (LBS or 1000 Gr) –
Selects the unit of measure of your calibration
test weights (lb or kg).
SCALE or CLASS – Selectable only when
calibrated in LBS (lb) mode. Selection of SCALE
rounds weight at 0.5 divisions. Selection of
CLASS sets device up as a weight classifier
rounding at 0.9 divisions.
Calibration Mode
