Model 7800 Family Weight Classifiers User’s Manual 20
The Configuration (CONF) mode menu allows
scale configuration for your specific application
needs. The items you can configure are as
follows:
FILTERING (FILT) – Choose between FAST and
SLO filtering. SLO should be chosen in areas
susceptible to vibration. Choose FAST filtering
for more stable conditions.
Baud (BAUD) – Choose a baud and parity from
Table 2.
Protocol (PROT) – Select the RS-232 commun-
ication protocol.
NCI – NCI standard
8213 – 8213 compatible (Mettler-Toledo)
3835 – NCI 3835
SMA – Scale Manufacturing Association
AUTO-1 – Auto print operation (Type-1)
AUTO-2 – Auto print operation (Type -2)
PRINT – Manual print operation
PRTOUT – Choose an output data format from
Table 3 for use with AUTO-1, AUTO-2 or PRINT
protocol selection.
Access the menu mode as described in Access-
ing the Menu Mode.
1. From the DIAG display, press the ZERO key
until CONF is displayed, or from the normal
weighing mode, move Switch 1 to the Menu
ode or the OPEN position; then press the
ZERO key until CONF is displayed.
Configuration Mode
