Model 7800 Family Weight Classifiers User’s Manual 14
The NCI 7800 bench scales allow calibration
using less than full capacity weights. See Table 1
for alternative weights that can be used to
calibrate your scale for its designated capacity.
Alternative
Capacity Calibration Weights
100 x .02 lb 10, 50, 100 lb
50 x .01 kg 10, 25, 50 kg
150 x .05 lb 10, 50, 150 lb
60 x .02 kg 10, 30, 60 kg
150 x .02 lb 10, 50, 150 lb
75 x .01 kg 10, 50, 75 kg
75 x .02 kg 10, 50, 75 kg
250 x .05 lb 50, 100, 250 lb
100 x .02 kg 10, 50, 100 kg
300 x .1 lb 50, 100, 300 lb
150 x .05 kg 10, 50, 150 kg
Display Baud Parity
12 E 1200 Even
24 E 2400 Even
48 E 4800 Even
96 E 9600 Even
19.2 E 19.2K Even
12 o 1200 Odd
24 o 2400 Odd
48 o 4800 Odd
96 o 9600 Odd
19.2 o 19.2K Odd
12 n 1200 None
48 n 4800 None
96 n 9600 None
19.2 n 19.2K None
*Default Factory Settings
Alternative Calibration
Points
Table 1
Alternative
Calibration Points
Baud Rate and Parity
Options
Table 2
Baud Rate and
Parity Options *
The databits and stop
bits default values are
7 data bits and 1 stop
bit. These are not
configurable.
