27
Zero Range
(Zrange)
Selects the range within which the scale may be zeroed. Note
that the scale must be in standstill to zero the scale.
100%
1.9%
Motion Band
(MotBand)
Sets the level at which motion is detected by comparing the
present display update with the previous one. If motion is not
detected for two seconds or more, scale is in standstill and can
process a Print or Zero command. Maximum value varies
depending on local regulations.
0.25 d 0.5 d
1 d 3 d
5 d 10 d
Digital Filter
(DFltr)
Sets the scale’s digital filtering method. The auto setting is a
dynamic filtering algorithm which optimizes stability and response
time. The settings 8 to 128 employ an averaging algorithm and
the settings Full 8 to Full 32 employ a hybrid averaging/dynamic
filtering algorithm.
Auto
8, 16, 32, 64, 128
Full 8, Full 16,
Full 32
Overload Limit
(OverLd)
Selects the desired formula which determines the point at which
the scale shows overload. All selections are based on the
primary calibration unit.
"FS" = Full scale in primary units.
FS
FS + 2%
FS + 1d
FS + 9d
Calib. Unit
(CalUnt)
Selects the primary base unit to be used in the calibration
process. Also the default unit for normal operation.
lb
kg
Display Divisions
(DspDiv)
Determines the desired weight increments. Value should be
consistent with legal requirements.
1 2 5
Decimal Pt.
(DecPnt)
Determines location of the decimal point. 0, 0.0, 0.00, 0.000
0.0000, 0.00000
00
TABLE 5-5: Local/Remote Scale Sub-menu Items
1. Press the soft key for each parameter listed in table 5-4. Each parameter will display
soft key choices for setup. Select the desired soft key and press ENT to select.
5.4.7 SETCOM Allows configuration and selection of COM ports
The configuration items for both serial ports (COM1 and COM2) are mostly identical in content. Table
5-5 lists the items which are available to be configured for each serial port.
1. From the service menu, press the SETCOM soft key.
2. Press the COM1 or COM2 soft key to configure the serial port of your choosing. The
sub-menu items are listed above the six soft keys.
3. Press the soft key pertaining to the parameter you wish to modify. The scale shows the
current status or selection of that item in the form of a highlighted soft key text.
4. Press the soft key corresponding to the desired status then press the ENT key. You may
exit this screen without making changes by pressing the CLR key.
5. Repeat steps 3 and 4 above until the configuration is complete.
6. Press the CLR key twice to return to normal operating mode.
