26
5.4.3 KcalZR Allows re-entry of the zero counts from last calibration
1. Press the KcalZR soft key.
2. Scale prompts “Select local or remote for calibration”.
3. Press the local or remote soft key or exit soft key to exit calibration
4. Scale displays “Key in Zero Counts XXXXXX “ where XXXXXX is the existing value for
zero counts from the last calibration. The first digit is blinking and will accept new values
entered from the keyboard. Either enter a new value and press ENT or press ENT to
accept the displayed value.
5. Scale prompts “Zero count is:XXXXXX.
6. Press the Yes soft key to accept or No soft key to return to step 4.
5.4.4 KCalSP Allows re-entry of the full scale counts from last calibration
1. Press the KcalSP soft key
2. Scale prompts “Select local or remote for calibration”.
3. Press the local or remote soft key or exit soft key to exit calibration
4. Scale displays “Key in Full Scale Counts XXXXXX “ where XXXXXX is the existing
value for full scale counts from the last calibration. The first digit is blinking and will
accept new values entered from the keyboard. Either enter a new value and press ENT
or press ENT to accept the displayed value
5. Scale prompts “Full Scale counts is:XXXXXX.
6. Press the Yes soft key to accept or No soft key to return to step 4
5.4.5 LOCAL Sets scale operation parameters for graduation size, creep tracking,
zero tracking, zero range, motion band, digital filter, overload point, calibration unit,
displayed division size, decimal point See Table 5-4.
5.4.6 Remote Sets scale operation parameters for graduation size, creep tracking,
zero tracking, zero range, motion band, digital filter, overload point, calibration unit,
displayed division size, decimal point See Table 5-4
PARAMETER
(Soft Key Text)
DESCRIPTION AVAILABLE
CHOICES
Graduations
(Grads)
Specifies number of full scale graduations. Value should be
consistent with legal requirements and environmental limits on
the useful system resolution.
1,000 1,500
2,000 2,500
3,000 4,000
5,000 6,000
7,500 8,000
10,000 12,000
15,000 20,000
24,000 30,000
40,000 50,000
100,000
Span N/A
Creep Tracking
(CrpTrk)
Sets the range within which the scale will attempt to offset the
effects of load cell creep. Use a lower setting for lower capacity
load cells and vice-versa. Selections are in seconds.
Off
1, 3, 5, 10, 15,
20, 30, 50, 60,
120, 180, 240
Zero Track Band
(Ztrack)
Selects the range within which the scale will automatically zero.
Note that the scale must be in standstill to automatically zero.
Selections are in Display Divisions.
0 d, 0.5 d, 1 d
3 d , 5 d
