25
ITEM SOFT
KEY
DESCRIPTION
Calibration of 650 or remote platform CALIB Allows you to enable or disable the
controlled accuracy feature
Zero Count Value/ re-entry KCalZR Allows re-entry of zero point value without
going through calibration procedure
Full scale count value/ re-entry KcalSP Sets the amount of filtering on the TC2010
platform
Allows setting and changing of 650
parameters
LOCAL Sets scale operation parameters for
graduation size, creep tracking, zero
tracking, zero range, motion band, digital
filter, overload point, calibration unit,
displayed division size, decimal point
Allows setting and changing of
remote platform parameters
REMOTE
Allows setting and changing of COM
port setups
SETCOM Sets serial protocol for COM ports
Allows global scale reset to factory
defaults
SETDEF Resets all scale parameters to factory
defauts
Sets display backlight. LIGHT Either always on or conservation mode to
save power for battery operation
TABLE 5-4: Service sub-menu items
5.4.1 CALIB – THREE POINT CALIBRATION
1. Press the soft key CALIB
2. Scale prompts “Select local or remote for calibration”.
3. Press the local or remote soft key or exit soft key to exit calibration
4. The scale prompts “Remove all weights and press enter”.
5. Remove all weight from the scale platform and press the ENT key.
6. The scale prompts “please weight” and briefly displays the zero count value and then
displays “Zero Calibration Done”
7. After computing the zero point the scale prompts “Input test weight in pounds (CAL
Point 1)
8. Enter the test weight value. For CAL point one use a test weight of at least 10% of the
scale capacity and press ENT.
9. The scale prompts “Put test weight on the press enter”
10. Place the test weight on scale and press ENT.
11. The scale briefly displays the count value for CAL point one.
12. Follow the prompts for CAL point 2 and 3. Use approximately 50% of the scale capacity
for CAL 2 and close to 100% of scale capacity for CAL 3.
13. If the calibration was completed successfully, the scale briefly display “Calibration
Passed”
5.4.2 CALIB – SINGLE POINT CALIBRATION
1. Follow steps 1 – 11 in 5.4.1.
2. When the scale prompts “Input test weight in pounds (CAL Point 2) enter 0 the press
ENT
3. The scale prompts “Abort Point 2 CAL?”
4. Press the YES soft key.
5. The scale prompts “Multi point cal aborted” and returns to the service sub-menu.
