CONFIGURATION MODE DEFINTIONS

Below is the definition of the configuration setting and the scale operations they affect

Mode -

Select the capacity of the scale

Mode

Capacity

CS_ _6

(6KG)

12 LB

CS_15

(15KG)

30 LB

CS_30

(30KG)

60 LB

CS_60

(60KG)

150 LB

CS_150

(150KG)

300 LB

CS_300

(300KG)

600 LB

** Shaded areas indicate C3255 capacities available

Units –

Configure each units of measure; LB, KG, oz, to On or Off. When selected units of measure is

turned off, the selection will not appear when pressing the mode key.

The default setting is ON

for all units of measure.

DivS –

Select the displayed resolution of the scale for the selected capacity chosen.

The default setting

is the NTEP approved capacity and resolution.

A.OFF –

To help save battery life, configure the scale to automatically shutoff after 120, 180, 240, 300

seconds or turns the setting OFF if you have the unit plugged into an AC outlet at all times.

The

default setting is ON.

CaL_U –

Select the calibration weight used when calibrating your scale.

The default setting is Full.

CAL_u-

Select the units of measure for calibration, KG or LB.

The default setting is LB

Count –

Shows raw counts of load cell and enters into calibration mode

trAd –

Configure the scale for OFF (Non-TYPE approved or sealed) or ON (Select this feature

when

calibration the unit for weights and measures sealing. With the Selection ON, only A.OFF

is configurable through the keyboard configuration menu. Press the sealing switch located

under the battery compartment to enter into all other configuration modes.

End –

Exits the configuration mode and returns to normal weighing mode.
