CALIBRATION PROCEDURE – NON- SEALED
There are two methods of calibrating the scale. Non –sealed, when the TrAd configuration is set
to off and Sealed, when the TrAd configuration setting is to on. These instructions help you
calibrate the scale, when it is in the non-sealed mode.
Periodically your scale may require calibration to ensure proper weighing. You will need a pre-
calibrated or accurate weight to calibrate the scale. If calibration is performed with a weight other
than a pre-calibrated or accurate weight, it will cause your scale to weigh inaccurately. Scale
calibration is accomplished, when needed, by the following instructions
FUNCTION SCALE RESPONSE
1. Remove all weight from the platform, and
make sure the scale is in a level and stable
environment.
2. Press and hold the SET key for three
seconds to enter into the configuration mode.
Scale displays “Mode”
3. Press the CALL key 4 times to “ CAL_U”,
press the Set key. The “ CAL_U” function
allows you to set the capacity of the calibration
weight .
Scale displays “FULL”.
4. Press the CALL key to scroll through to
choose 1 / 2 and 1 / 4. See Table 3 for valid calibration
weights required
5. Once you have selected the calibration
weight, press the SET key once.
Scale displays “CAL_U”.
6. Press the CALL key once
Scale displays “CAL_u”.
The “CAL_u” configuration setting allows you to configure the scale to calibrate in pounds or
kilograms.
7. Press the SET key once
Scale displays “lb”
8. Press the CALL key to scroll through to
choose lb and kg . Once you have selected
the calibration weight, press the SET key once.
Scale displays “CAL_u”.
9. Press the CALL key once to scroll to
“ Count ”. Press the SET key once.
Scale displays “ XXXXXX” (Raw counts
At zero weight)
10. Press the TARE key once to zero the scale.
