Attaching Lens Cap Cord
26 - a
1. Pass the cord provided through the
loop on the lens cap.
2. Pass the grip belt through the ring
of cord. Then pass the grip belt
through the loop on the camera as
shown.
Removing and Attaching Lens Cap
and Lens Hood
26 - b
Remove lens cap before recording and hook it
onto grip belt using clip on lens cap. Replace
lens cap when you stop recording or turn the
camera off.
Q Focusing Ring
IS Filter (option)
B Lens Hood
B Lens Cap
To remove the lens hood:
Rotate it 60° counter-clockwise, as shown, and
remove.
To attach the lens hood:
Rotate it 60° clockwise until it clicks into place.
• When using a filter, attach the lens hood in
front of the filter so that the lens cap can be
replaced.
Adjusting Grip Belt 26-c
Tighten or loosen grip belt as necessary for a
comfortable fit. Hold grip with your right hand
whiie adjusting grip belt with your left.
