WL-50 Wireless Controller
Using the wireless controller you can operate
the camera from a distance,
O
Transmitter
Q F. (Fade) START/STOP Button
O ON SCREEN Button
O FF ►► Button
O PLAY ► Button
O STILL ►N Button
O RFC # Button
O
STOP ■ Button
O REW « Button
0 TAPE RETURN Button
0 COUNTER RESET Button
0 ZOOM Buttons
0 START/STOP Button
Operation iTiH=l
Aim wireless controller at camera remote
sensor and press control buttons to operate
camera. Remote sensor is located just below
the microphone. Use wireless controller within
4 metres of the camera. The tally lamp, located
above and to the right of lens, lights up when
remote sensor receives a signal.
0 Remote Sensor
0 Tally Lamp
10
Notes:
• When using wireless controller check that it lights up the tally lamp. If tally lamp lights, wireless
controller can be used from that position.
• If you are too close to camera when operating wireless controller, camera may not respond to wireless
controller’s signal.
