Canon E 200 User Manual
E200, Canon
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".
Table of contents
Document Outline
- Canon E200
- Table of Contents
- Camera Parts and Functions
- WL-50 Wireless Controller
- Viewfinder Dispiays
- Power Sources
- Attaching Battery Pack BEI
- 1. Slide battery pack into power source compartment.
- 2. Press battery pack until it clicks and locks In place.
- Removing Battery Pack BB3
- 1. Slide and hold ВАТТ EJECT switch up.
- 2. Pull battery pack out, as shown.
- Charging Battery Pack
- Using AC Power
- CA-100 Compact Power Adapter
- Using Car Battery
- CB-110 Car Battery Adapter (option)
- N Attaching DC Coupler
- 1. Insert D0100 DC Coupler into power source compartment.
- 2. Connect DC-100 cable to compact power adapter (or car battery adapter).
- Inserting New Lithium Battery
- Setting Date and Time
- 0
- 3. Press + and - buttons to scan year display.
- 4. Press SHIFT button when correct year is shown.
- 5. Press + and - buttons to scan month display.
- 6. Press SHIFT button when correct month is shown.
- 7. Press + and - buttons to scan day display.
- 8. Press SHIFT button when correct day is shown.
- 9. Press + and - buttons to scan hour display.
- 10. Press SHIFT button when correct hour is shown.
- 11. Press + and - buttons to scan minute
- display.
- 12. Press DATE button when correct minute is shown.
- Camera Preparations
- Attaching Strap
- SS-300 Shoulder Strap
- WS-20 Wrist Strap (option)
- Adjusting Diopter 25-a
- Adjusting 180 FtexiGrip with Integral Electronic Viewfinder 25-b
- Sports Finder 25-c
- 2.
- Attach power source.
- Turn camera on.
- Press A (EJECT) button.
- Load video cassette and close video cassette compartment.
- Press l^/LP button to select tape mode.
- Turn grip to desired position.
- 7. Press start/stop button.
- 8. Press start/stop button again to temporarily pause recording. ^0
- 9. When recording has ended, press A (EJECT) button.
- 10. Remove video cassette and close video cassette compartment again.
- 11. Turn camera off.
- Video cassette erasure prevention switch
- Tape Counter
- Recording Reminder
- Record Search
- Record Review
- Edit-erase
- Recording Date and Time
- 1. While recording or in record pause mode, press DATE button. Biffl
- 2. Press DATE button again to end date and time recording.
- Autofocus
- Subjects Not Suitable for Autofocus
- Manual Focus
- 1. Press FCX^US IS/M button to select manual focus.
- 2. Rotate zooming lever to telephoto end.
- 3. Look through viewfinder and rotate focusing ring to focus on subject.
- 4. Use zooming lever to frame subject properly.
- Focus Lock
- 1. Press FOCUS IS/M button to select manual focus.
- 2. Rotate zooming lever to wide-angle end.
- 3. Press and hold macro button on zooming lever and move lever into macro range.
- 4. Approach subject to desired size in viewfinder.
- 5. Use zooming lever within macro range for fine focusing.
- 6. When macro recording is completed, reverse steps 2 and 3.
- Power Zoom 4o-a
- Manual Zoom 4o-b
- Wireless Zoom 4o-c
- Shooting with Video Light
- Attaching Video Light 4i-a
- 1. Insert video light plug into accessory shoe on the camera.
- 2. Slide video light into accessory shoe until it stops.
- Removing Video Light 4i-b
- 1. Press and hold lock release button.
- 2. Slide video light out of accessory shoe.
- Replacing Bulb 43-a
- 1. Rotate the protector In the indicated direction.
- 2. Puli out the old bulb.
- 3. Insert a new bulb positioning the notch at the bottom.
- 4. Rotate the protector in the indicated direction.
- Gain-up/Backlight Compensation
- High-Speed Shutter
- Fade
- Adding Titles to Recordings
- Creating Character Titles
- 1. Place camera in record pause.
- 2. Press CHARACTER TITLE button for more than 3 seconds to display title lines in viewfinder.
- 3. Press SHIFT button to move the cursor to
- position where you want to start the title. BHa
- 4. Use -I- and - buttons to scan list of title characters.
- 5. When the character you want is displayed, press SHIFT button again to move to next cursor position.
- 6. Follow steps 4 and 5 until your title is complete.
- 7. When the title is finished, press CHARACTER TITLE button. BQ
- Playback Connection
- Using TV with Audio/Video Input Terminals
- Connection Procedure
- Using TV with SCART Terminal
- Connection Procedure Rgil
- Selecting Vídeo Channel (European model)
- 1. Turn TV on.
- 2. Turn camera on.
- 3. Press ■ (STOP) button to select playback mode.
- 4. Press A (PLAY) button to start playback.
- 5. Set RF unit’s G/l selector using flat-edge screwdriver.
- 6. Set TV and video channei selector to video channei (video channel selector is factory-set to CH 32).
- Using TV without Audio/Video Input Terminals (Australian Model)
- Selecting Vídeo Channel (Australian model)
- 1. Turn TV on.
- 2. Turn camera on.
- 3. Press ■ (STOP) button to select playback mode.
- 4. Press M (PLAY) button to start playback.
- 5. Set TV and video channel selector to video channei (video channel selector is factory-set to 1CH) using a flat-edge screwdriver.
- Playback Procedure
- 1. Turn camera on.
- 2. Press A (EJECT) button.
- 3. Load video cassette in camera and close video cassette compartment.
- 4. Press ■ (STOP) button to select playback mode.
- 5. Locate playback start point.
- 6. Press PLAY button to start playback.
- 7. Press ■ (STOP) button to end playback.
- 8. Turn camera off.
- High-Frequency Feedback
- Special Playback Methods
- Tape Return
- Editing to Another VTR
- 1,6
- Canon E200 Video System Chart
- Carrying Cases
- Optional Accessories
- Problems and Troubleshooting
- Condensation (DEW)
- Cautions
- During Use
- F. Always Replace the Lens Cap.
- G. Do Not Expose the Camera to Shock or Vibrations.
- H. Avoid Sudden Changes in Temperature.
- I. Do Not Disassemble the Camera.
- J. Using the Battery Pack and Recommended Accessories.
- Using Your Battery Packs Effectively
- immediateiy After Purchase
- General Use
- storage
- Terminology
- Maintenance
- Keep the Heads Clean.
- Clean the Camera with a Soft, Dry Cloth.
- Store the Camera Properly.
- Store Cassette Tape Properly.
- Check the Operation of Each Component.
- Specifications
