13
【The Following Applies to All Models.】
1. Check the clearance on each part before tightening everything.
Torque Specs Supplied flange nut M8【20～28 N・m (2.0～2.9 kgf-m)】
TYPE-60R/60S Clamp Band 【16 N・m (1.63 kgf-m)】
TYPE-80 Clamp Band 【25 N・m (2.6 kgf-m)】
2. Fit the springs onto each of the spring hooks.
*Use the supplied Springs
CAUTION
· Please check all clearances with the vehicles body and make sure that the bolts are not interfering
with anything else. The clearances can change from vehicle to vehicle. If the clearance isn't enough,
loosen the bolts on the catalytic converter side to adjust the clearance, then tighten the bolts
properly.
· After fitting, please check that there are no signs of oil, dirt so as not to burn them later when
the car is running.
· After fitting the exhaust, you should check if the rear bumper
will be at risk from heat from the pipe.
You may need to add extra heat shield protection on the
rear bumper.
3. If needed you can then install the sound reducer. (Ref⑫)
* Use the supplied Button Bolt M6 (Ref⑬)
TORQUE SPECS 【8～12 N・m (0.8～1.2 kgf-m)】
WARNING
* It is highly recommended not to use the sound reducer when using the car for high speed/ hard
driving as it may cause failure.
* Only install or remove the sound reducer when the engine and exhaust is cold to avoid any burns
or injuries.
4. Reconnect the cars battery negative terminal.
3. INSTALLATION VERIFICATION
1. Check again the vehicle that there are no parts interfering with any other components.
2. Start the engine and let it idle first before taking it up to 2500 RPM to check and listen for any signs
of exhaust leaks or any abnormal sounds. Then recheck the car again for any loose parts or gas leaks.
3. After the initial test drive check the car again for any signs of exhaust gas leakage and any loose
parts, bolts and nuts.
CAUTION
· Any interference with any parts/components can pose a fire risk hazard so please meticulously check
the car after the install.
· Any exhaust leaks can decrease performance efficiency and also pose a health risk hazard with toxic
exhaust gas poisoning.
· If there is anything felt abnormal when driving please stop immediately and check the car over.
· When any work or checks are to be done with the metal exhaust components then please do so when
it is cold to prevent any burns and injuries.
· If any parts are lost or have fallen off then does not restart the car until the missing parts can be
replaced properly.
