Tomei Powered UNIVERSAL OIL PAN BAFFLE PLATE - Manual (Page 5)

KIT CONTENTS
Below is the contents of this kit with the quantity listed in brackets ().
REQUIRED TOOLS
These tools are the bare minimum required for the job.
・General Maintenance Tools ・Workshop Service Manual ・Threadlock Paste
・Torque Wrench ・Drill Φ5mm ・M6- P1.0 Tap
・Rivet or welder (or similar)
CAUTION
■ This product is designed for competition used ONLY. Not to be used on public roads.
■ The original safety standards of the vehicle will change which will make it illegal to be used on public roads.
■ This product is to be fitted by an experienced professional in a fully equipped workshop.
■ Check for any signs of interference with the product during installation.
Baffle Plate (4) Bracket (4)
Rubber Valve (10)
※2 are spare
Bolt M6 (4)
Sticker (2)
5
■ Check for any signs of interference with the product during installation.
■ Tighten each bolt with the torque specified with a torque wrench. If the bolt(s) loosens, damage to the engine
may result. Additional problems may arise if the bolts are not tightened to the specified torque specs.
■ Check regularly that everything is tightened and secured properly.
■ Do not use excessive force when removing and installing parts. As this may cause damage to the parts and
related components.
■ This product is to be fitted with the correct tools, protective & safety equipement. Failure to do so can lead to
possible work hazards.
■ Clean the product throughly before use to remove any unwanted protective coating, grime on the item.
■ Using a good quality external oil cooler is also highly recommended.
WARNING
■ This product is to be installed when the engine and engine bay is cold.
■ Check with care that all parts are fitted correctly to avoid any possible fire risk hazards.
■ Make best use of other oil management gauges after installation.
If oil is insufficiently supplied back to the oil pan, the engine can result in terminal engine failure.
