5
CS SERIES
CS SERIES Control System Specifications
Control Type: LN
2
Level Control & Temperature Control
Level Measurement Sensor Type: 8-Thermistor Fixed
4-Thermistor Adjustable
Range: 8 inch range (8-Thermistor)
Low, Normal, High (4-Thermistor)
Redundancy Multiple discrete points
Temperature Measurement: Sensor Type: Type T Thermocouples
Accuracy of 1.5% with Resolution of 0.1°c
Number of Channels: 2
Temperature Display Units: °C, F, K, R
Electrical: Input Voltage: 100-240 VAC
Input Current (max: 1.75 A
Input Current (continuous): 0.5 A
Power Consumption (max): 21 W
Power Consumption (continuous): 6 W Input
Frequency: 50/60 Hz
Output: 12 VDC
Control Input Voltage: 12 VDC
Power Cord: Available for all countries
Battery: Rating: 12 Volt, 18Ah
Type: Absorbent Glass Mat (AGM) Sealed Non-
Spillable
Short Protection: Installed PCB with thermal fuse
Battery Cover: Vinyl
Solenoid Valve Input Voltage: 12 VDC
Input Current 0.96 amps
Communications: Protocol: Connectivity Access Network (CAN)
Number of Communication Ports: 3
User Interface: Display Type Vacuum Fluorescent
Display: (VFD)
Buttons:11
Level, Temperature and Alarm
Information
“At a Glance” Status LED status wheel
Filling 1 LED
Menu Access 1 LED
Power LED
Control Tests: Power Up Self Test Control System Check
Thermistor Status
Battery voltage
Control voltages
Temperature Circuit
Alarms: Low Level Alarm: Always enabled
High Level Alarm: Always enabled
Sensor Error Alarm: Always enabled
High Temperature Alarm: (T/C #1, T/C #2)
Programmable
