Management Terminal Setup
6H122-16 User’s Guide 5-3
5.3 MANAGEMENT TERMINAL SETUP
Use one of the following systems to access Local Management:
• An IBM or compatible PC running a VT series emulation software
package
• A Digital Equipment Corporation VT100 type terminal
• A VT type terminal running emulation programs for the Digital
Equipment Corporation VT100 series
• A remote VT100 type terminal via a modem connection
• In-band via a Telnet connection
5.3.1 Console Cable Connection
Use the Console Cable Kit provided with the 6C105 chassis to attach the
management terminal to the COM port as shown in
Figure 5-1 .
Connect an IBM PC or compatible device, running the VT terminal
emulation, to the 6H122-16 as follows:
1. Connect the RJ45 connector at one end of the cable (supplied in the
kit) to the COM port on the 6H122-16.
2. Plug the RJ45 connector at the other end of the cable into the
RJ45-to-DB9 adapter (supplied in the kit).
3. Connect the RJ45-to-DB9 adapter to the PC communications port.
NOTE
If using a VT100 style terminal, use the RJ45 to DB25 adapter
included in the Console Cable Kit, instead of the PC adapter.
