Module Statistics Menu Screen
6H122-16 User’s Guide 5-85
3. Use the arrows keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” is displayed, and the Reset
Peak Switch counter is reset to zero.
5.25 MODULE STATISTICS MENU SCREEN
The Module Statistics Menu screen, Figure 5-34 , provides access to
screens that allow the user to obtain switch statistics about frame traffic
through each interface, to view MIB-II statistics from each interface, and
to view RMON Statistics gathered by the RMON agent embedded in the
6H122-16.
To access the Module Statistics Menu from the Module Menu screen, use
the arrow keys to highlight the MODULE STATISTICS menu item and
press ENTER. The Module Statistics Menu
screen displays.
NOTE
The SWITCH STATISTICS menu item on the Module Statistics
Menu screen will not display if the operational mode of the
module has been set to SECURE FAST VLAN.
Section 5.15.9 provides instructions on setting the operational
mode.
