SR870BN4 Error Reference Guide SR870BN4 SEL Data Tables
Revision 1.0 3
3. SR870BN4 SEL Data Tables
The tables in this section provide information on the data provided by the SEL Viewer utility.
3.1 SR870BN4 Generator ID Codes
Generator ID Description
20 00 BMC
C0 00 HSC
0x31 00 -0x3F 00 System BIOS or
System SW
3.2 SR870BN4 Sensor Codes
Sensor
Type
Sensor
Number Sensor Name
01 Temperature
01h SCSI BP Temperature
30h Memory Board 1 Temp
31h Memory Board 2 Temp
32h IO Board Temp 1
33h IO Board SIOH Temp
34h IO Board Temp 3
35h CPU Board Amb Temp
36h CPU Board SNC Temp
98h Proc 1 Temp
99h Proc 2 Temp
9Ah Proc 3 Temp
9Bh Proc 4 Temp
02 Voltage
10h IO Board +1.3V
11h IO Board +1.5V
12h IO Board +1.8V
15h IO Board +3.3V SB
16h IO Board +3.3V A
17h IO Board +3.3V B
18h IO Board V
BAT
19h IO Board +5V A
1Ah IO Board +5V B
1Bh IO Board +12V
1Ch IO Board -12V
1Dh CPU Board +1.2V
1Eh Memory Board 1 +1.25V
1Fh Memory Board 2 +1.25V
20h CPU Board +1.3V
21h CPU Board +1.5V
