POST Codes
SR870BN4 Error Reference Guide
Revision
1.0
28
Code Value
Module
Display
0x0099
Configuring the timer data area and printer base address.
South
0x009B
Returned after setting the RS-232 base address. Performing any required initialization
before the Coprocessor test next.
South
0x009E
Initialization after the Coprocessor test is complete. Checking the extended keyboard,
keyboard ID, and Num Lock key next. Issuing the Keyboard ID command.
South
0x00A2
Displaying any soft errors.
South
0x00A3
The soft error display has completed. Setting the keyboard typematic rate.
South
0x00A4
The keyboard typematic rate is set. Programming the memory wait states next.
South
0x00A5
Memory wait state programming is over. Clearing the screen.
South
0x00A7
Performing any initialization required before passing control to the adaptor ROM at
E000 next.
South
0x00AE
Setting up DMI structures.
South
0x0020
Talking to BMC
South
0x0022
Talking to BMC.
South
0x00AC
Uncompressing the DMI data and initializing DMI POST.
South
0x00AB
Building the multiprocessor table.
South
0x00AD
Prepare INT10 image. Update the necessary data in different modules.
South
0x00A8
Initialization before passing control to the adaptor ROM at E000h completed. Pass
control to the adaptor ROM at E000h.
South
0x00A9
Returned from adaptor ROM at E000h control. Performing any initialization required
after the E000 option ROM had control next.
South
0x00AA
Initialization after E000 option ROM control has completed. Displaying the system
configuration.
South
0x00B1
Copying any runtime code to specific areas.
South
0x0000
Code copying to specific areas is done. Pass control to EFI.
South
7.2.2.5 EFI
Module
The EFI POST codes have been redefined relative to previous platform implementations. Note
the addition of the module number and that bit 15 is set, indicating code for Itanium-based
platforms.
Table 10. EFI POST Codes
Code Value
Module
Display
0x85F0
Initialize the EFI FW memory map.
South
0x85F1
Set up interrupt vector mappings in interrupt controller for EFI.
South
0x85F2
Memory map installed.
South
0x85F3
Basic EFI services are now functional. Although no devices or variable store support is
on line. InitializeLib.
South
0x85F4
Init Watchdog Timer. Initialize support for calling BIOS functions Initialize Bios Int Caller.
Install base devices. This would at least include a global_IO device, all NV ram store
device(s), and the timer tick. It may optionally include other_IO devices. Install Base
Devices.
South
0x85F5
Nv Store installed.
South
0x85F6
Install consoles device, and notify EFI FW to pick and enable a console.
South
0x85F7
Consoles installed.
South
