SR870BN4 Error Reference Guide POST Codes
Revision 1.0 21
0x8F72 Validate DIMMs (Mem_ValidateInstalledConfiguration()) North
0x8F73 Program MIRs/MITs (Mem_DoMirMitProgram()) North
0x8F74 Calculate CAS (Mem_CalcSysCas()) North
0xCF74 Calculate CAS Error Loop North
0x8F75 Program CAS (Mem_SetMrhdCasLatency()) North
0x8F76 Set Mrhd DIMM Geomentry (Mem_SetMrhdDimmGeometry()) North
0x8F77 Perform SLEW rate calibration (Mem_DoSlewRateCalibration) North
0x8F78 Mem_InitDimmAndSetCasLatencyAndBurst() North
0x8F79
DDR delay Calibration (Mem_DoDdrDelayCalibration()) North
0x8F80 DIMM path latency Calibration North
0x8F81 DIMM Strobe Delay Calibration North
0x8F82 Configure SNC timing North
0x8F83 Set timings for write pattern North
0x8F90 Levelization North
0x8F98 Reconfigure memory North
0xCF9F Levelization failed. No Memory Found North
0x8F60 Memory Test North
0x8F50 Platform Discovery North
0x8F40 SBSP selection North
0x8F50 Platform Init North
0x8F20 Memory Autoscan entry North
0x8F21 Process Auto Scan Input North
0x8F22 Process Auto Scan Output North
0x8F10 Recovery code entry North
0x8ED0 Recovery C-Code Entry North
0x8ED1 Recovery Reading media North
0xCEDF Recovery Reading error North
0x8EC0 Recovery program start North
0x8EC1 Recovery program success North
0xCECF Recovery programming error North
0x8E80 PEIM Handoff block entry North
0x8C00 SALA to SALB/DXE handoff North
0x8AF0
to
0x8800
Reserved for MCA, INIT, PMI North
7.2.2.2 SAL-B Module
Table 7. SAL-B POST Codes
Code Number BSP, APs,
Both Meaning Display
0x87FF BSP+APs First check point. Initialize
cr.iva/ar.eflag/ar.cflg/cr.lrr0/cr.lrr1/cr.ifa/cr.itir South
0x87FE BSP only Initialize io_base address, CPU#, health, etc. for CPU's. Initialize South
