SR870BN4 SEL Data Tables SR870BN4 Error Reference Guide
Revision 1.0 4
Sensor
Type
Sensor
Number Sensor Name
22h CPU Board +1.8V
23h CPU Board +3.3V SB
24h CPU Board +12V SB
25h IO Riser Board +12V SB
26h IO Riser Board +2.5V
27h IO Riser Board +1.5V SB
28h IO Riser Board +1.5V
29h IO Riser Board +5V SB
2Ah I/O Board SCSI +5V
60h LVDS SCSI channel 1 terminator 1
61h LVDS SCSI channel 1 terminator 2
62h LVDS SCSI channel 1 terminator 3
63h LVDS SCSI channel 2 terminator 1
64h LVDS SCSI channel 2 terminator 2
65h LVDS SCSI channel 2 terminator 3
7Eh CPU Board 12V SB Power Good
7Fh Node Power Good
A4h Proc 1 Power Pod Good
A5h Proc 2 Power Pod Good
A6h Proc 3 Power Pod Good
A7h Proc 4 Power Pod Good
04 Fan
40h Tach Fan 1
41h Tach Fan 2
42h Tach Fan 3
43h Tach Fan 4
82h Fan 1 Present
83h Fan 2 Present
84h Fan 3 Present
85h Fan 4 Present
06 Security Violation Attempt
04h Platform Security Violation
07 Processor
90h Proc 1 Status
91h Proc 2 Status
92h Proc 3 Status
93h Proc 4 Status
08 Power
Supply
70h Power Supply 1
71h Power Supply 2
74h I/O Board 3.3V D2D 3
75h I/O Board 3.3V D2D 2
76h I/O Board 5V D2D 1
