Table 1F — 40RMS Physical Data, SI — Chilled Water Units
UNIT 40RMS
008
010
012
014
016
024
028
034
NOMINAL CAPACITY (kW)
26
29
35
43
52
70
87
105
OPERATING WEIGHT (kg)
Base Unit
177
177
177
300
307
310
469
473
Plenum
80
80
80
102
102
102
148
148
FANS
Qty...Diam. (mm)
1...381
1...381
1...381
2...381
2...381
2...381
2...457
2...457
Nominal Airflow (L/s)
1416
1605
1888
2360
2831
3775
4719
5663
Airflow Range (L/s)
1062-1770
1204-2006
1416-2360
1770-2949
2124-3539
2831-4719
3539-5899
4247-7079
Nominal Motor kW
(Standard Motor)
208/230-1-60
1.79
1.79
—
—
—
—
—
—
208/230-3-60, 460-3-60
1.79
1.79
1.79
1.79
2.76
3.73
5.60
7.46
575-3-60
1.49
1.49
1.49
1.49
2.24
3.73
5.60
7.46
230-3-50, 400-3-50
1.79
1.79
2.16
2.16
2.16
3.73
5.60
7.46
Motor Speed (r/s)
208/230-1-60
28.8
28.8
—
—
—
—
—
—
208/230-3-60, 460-3-60
28.8
28.8
28.8
28.8
28.8
29.1
29.1
29.1
575-3-60
28.8
28.8
28.8
28.8
28.8
29.1
29.3
29.3
230-3-50, 400-3-50
23.8
23.8
23.8
23.8
23.8
23.8
23.8
23.8
CHILLED WATER COIL
Enhanced Copper Tubes, Aluminum Sine-Waves
Max Working Pressure (kPag)
2999
Face Area (sq m) — Upper
0.77
0.84
0.91
0.77
0.77
1.02
1.15
1.44
Face Area (sq m) — Lower
—
—
—
0.51
0.77
0.77
1.15
1.15
Rows...Fins/m
3...591
3...591
3...591
3...591
3...591
3...591
3...591
3...591
STEAM COIL
Max Working Pressure
(kPag at 126 C)
138
Total Face Area (sq m)
0.62
0.62
0.62
1.24
1.24
1.24
1.39
1.39
Rows...Fins/m
1...355
1...355
1...355
1...355
1...394
1...394
1...394
1...394
HOT WATER COIL
Max Working Pressure (kPag)
1034
Total Face Area (sq m)
0.62
0.62
0.62
1.24
1.24
1.24
1.39
1.39
Rows...Fins/m
2...335
2...335
2...335
2...335
2...335
2...335
2...493
2...493
Water Volume
(L)
31.4
52.6
54.1
(m
3
)
0.031
0.052
0.054
PIPING CONNECTIONS,
Quantity...Size (in.)
Chilled Water — In
1...1
3
/
8
ODF
1...1
3
/
8
ODF
2...1
3
/
8
ODF
2...1
3
/
8
ODM 2...1
3
/
8
ODM 2...1
3
/
8
ODM 2...2
1
/
8
ODM 2...2
1
/
8
ODM
Chilled Water — Out
1...1
3
/
8
ODF
1...1
3
/
8
ODF
2...1
3
/
8
ODF
2...1
3
/
8
ODM 2...1
3
/
8
ODM 2...1
3
/
8
ODM 2...2
1
/
8
ODM 2...2
1
/
8
ODM
Steam Coil, In (MPT)
1...2
1
/
2
1...2
1
/
2
Steam Coil, Out (MPT)
1...1
1
/
2
1...1
1
/
2
Hot Water Coil, In (MPT)
1...1
1
/
2
1...1
1
/
2
1...2
Hot Water Coil, Out (MPT)
1...1
1
/
2
1...1
1
/
2
1...2
Condensate (PVC)
1...1
1
/
4
ODM/1 IDF
FILTERS
Throwaway — Factory Supplied
Quantity...Size (mm)
4...406 x 610 x 51
4...406 x 508 x 51
4...508 x 610 x 51
4...406 x 610 x 51
4...508 x 635 x 51
Access Location
Either Side
