23

Table 5 — Electrical Data, Alternate Motors

Legend and Notes For Tables 4 and 5

LEGEND

*Motors are designed for satisfactory operation within 10% of nominal volt-

ages shown. Voltages should not exceed the limits shown in the Voltage Lim-
its column.

NOTES:
1. Minimum circuit amps (MCA) and MOCP values are calculated in accor-

dance with NEC (National Electrical Code), Article 440.

2. Motor FLA values are established in accordance with UL (Underwriters’

Laboratories) Standard 1995.

3.

Unbalanced 3-Phase Supply Voltage

Never operate a motor where a phase imbalance in supply voltage is
greater than 2%.

Use the following formula to determine the percentage of

voltage imbalance.

EXAMPLE: Supply voltage is 400-3-50.

AB = 393 v
BC = 403 v
AC = 396 v

Determine maximum deviation from average voltage.

(AB) 397 – 393 = 4 v
(BC) 403 – 397 = 6 v
(AC) 397 – 396 = 1 v

Maximum deviation is 6 v.
Determine percent voltage imbalance.

This amount of phase imbalance is satisfactory because it is below the maxi-
mum allowable 2%.

UNIT

V*-PH-Hz

VOLTAGE

LIMITS

FAN MOTOR

POWER SUPPLY

Hp (kW)

FLA

Minimum

Circuit Amps

MOCP

40RM

007

208/230-1-60

187-253

2.4 (1.79)

11.0/11.0

13.8/13.8

20

208/230-3-60

187-253

2.9 (2.16)

7.5

9.4

15

460-3-60

414-506

2.9 (2.16)

3.4

4.3

15

575-3-60

518-632

2.0 (1.49)

2.4

3.0

15

230-3-50

207-253

2.4 (1.79)

5.2

6.5

15

400-3-50

360-440

2.4 (1.79)

2.6

3.3

15

40RM

40RMQ

40RMS

008

208/230-1-60

187-253

2.4 (1.79)

11.0

13.8

15

208/230-3-60

187-253

2.9 (2.16)

7.5/7.5

9.4/9.4

15

460-3-60

414-506

2.9 (2.16)

3.4

4.3

15

575-3-60

518-632

3.0 (2.24)

3.8

4.8

15

230-3-50

207-253

2.9 (2.16)

7.5

9.4

15

400-3-50

360-440

2.9 (2.16)

3.4

4.3

15

40RMS

010

208/230-1-60

187-253

2.4 (1.79)

11.0

13.8

20

208/230-3-60

187-253

2.9 (2.16)

7.5

9.4

15

460-3-60

414-506

2.9 (2.16)

3.4

4.3

15

575-3-60

518-632

3.0 (2.24)

3.8

4.8

15

230-3-50

207-253

2.9 (2.16)

7.5

9.4

15

400-3-50

360-440

2.9 (2.16)

3.4

4.3

15

40RM

40RMQ

40RMS

012

208/230-3-60

187-253

3.7 (2.76)

10.5/10.5

13.3/13.3

20

460-3-60

414-506

3.7 (2.76)

4.8

6.0

15

575-3-60

518-632

3.0 (2.24)

3.8

4.8

15

230-3-50

207-253

5.0 (3.73)

15.2

19.0

30

400-3-50

360-440

5.0 (3.73)

7.6

9.5

15

40RM

40RMS

014

208/230-3-60

187-253

3.7 (2.76)

10.2

12.7

20

460-3-60

414-506

3.7 (2.76)

4.8

6.0

15

575-3-60

518-632

5.0 (3.73)

5.1

6.4

15

230-3-50

207-253

5.0 (3.73)

15.2

19.0

30

400-3-50

360-440

5.0 (3.73)

7.6

9.5

15

40RM

40RMQ

40RMS

016

208/230-3-60

187-253

5.0 (3.73)

14.6/12.8

18.3/16.0

30/25

460-3-60

414-506

5.0 (3.73)

6.4

8.0

15

575-3-60

518-632

5.0 (3.73)

5.1

6.4

15

230-3-50

207-253

5.0 (3.73)

15.2

19.0

30

400-3-50

360-440

5.0 (3.73)

7.6

9.5

15

40RM

40RMQ

40RMS

024

208/230-3-60

187-253

7.5 (5.59)

21.5/19.4

26.9/24.3

45/40

460-3-60

414-506

7.5 (5.59)

9.7

12.1

20

575-3-60

518-632

7.5 (5.59)

7.8

9.8

15

230-3-50

207-253

7.5 (5.59)

22.8

28.5

50

400-3-50

360-440

7.5 (5.59)

11.4

14.3

25

40RM

40RMQ

40RMS

028

208/230-3-60

187-253

10.0 (7.46)

28.2/26.8

35.3/33.5

60/60

460-3-60

414-506

10.0 (7.46)

13.4

16.8

30

575-3-60

518-632

10.0 (7.46)

10.3

12.9

20

230-3-50

207-253

10.0 (7.46)

32.2

40.3

60

400-3-50

360-440

10.0 (7.46)

16.1

20.1

30

FLA

Full Load Amps

MOCP

Maximum Overcurrent Protection

= 100 x

max voltage deviation from average voltage

average voltage

Average Voltage =

393 + 403 + 396

3

=

1192

3

= 397

% Voltage Imbalance = 100 x

6

397

= 1.5%

IMPORTANT:

If the supply voltage phase imbalance is more than

2%, contact your local electric utility company immediately.
