44
Table 11D — 40RM High-Capacity Fan Performance Data —
0-600 kPa External Static Pressure — SI (cont)
See Legend and Notes on page 45.
UNIT
40RM
AIRFLOW
(L/s)
EXTERNAL STATIC PRESSURE (kPa)
350 400 450 500 550 600
r/s kW r/s kW r/s kW r/s kW r/s kW r/s kW
007
850 15.34 0.80 16.25 0.92 17.10 1.03 17.90 1.16 18.66 1.28 19.39 1.41
850 15.69 0.94 16.61 1.07 17.47 1.20 18.28 1.33 19.04 1.47 19.77 1.61
1130 16.04 1.09 16.95 1.23 17.81 1.38 18.63 1.53 19.40 1.67 — —
1270 16.44 1.27 17.32 1.42 18.17 1.58 18.97 1.74 19.75 1.90 — —
1420 16.91 1.49 17.75 1.64 18.56 1.81 19.34 1.97 — — — —
008
1060 15.50 0.96 16.43 1.10 17.31 1.23 18.14 1.37 18.93 1.51 19.68 1.66
1230 15.84 1.14 16.75 1.28 17.62 1.43 18.45 1.58 19.24 1.74 — —
1420 16.34 1.38 17.19 1.54 18.01 1.70 18.81 1.86 19.59 2.03 — —
1600 16.97 1.69 17.76 1.85 18.52 2.02 19.27 2.19 — — — —
1770 17.61 2.01 18.35 2.18 19.07 2.35 19.77 2.53 — — — —
012
1420 16.02 1.33 16.87 1.48 17.71 1.64 18.52 1.80 19.30 1.97 — —
1650 16.76 1.70 17.53 1.85 18.29 2.02 19.04 2.19 19.77 2.37 — —
1890 17.64 2.16 18.35 2.33 19.05 2.51 19.74 2.69 — — — —
2120 18.60 2.73 19.28 2.91 19.93 3.10 — — — — — —
2360 19.61 3.40 — — — — — — — — — —
014
1770 15.21 1.78 16.19 2.06 17.13 2.34 18.04 2.64 18.91 2.94 19.75 3.25
2030 15.46 2.05 16.37 2.33 17.26 2.63 18.12 2.94 18.96 3.26 19.78 3.59
2360 15.94 2.46 16.78 2.77 17.60 3.08 18.40 3.40 19.18 3.73 19.94 4.07
2690 16.51 2.95 17.32 3.28 18.09 3.62 18.84 3.96 19.57 4.31 — —
2950 16.99 3.39 17.78 3.74 18.54 4.10 19.26 4.47 19.96 4.84 — —
016
2120 15.21 2.05 16.11 2.33 16.98 2.62 17.83 2.93 18.66 3.24 19.47 3.57
2500 15.69 2.49 16.54 2.80 17.35 3.12 18.14 3.44 18.90 3.77 19.64 4.11
2830 16.18 2.94 17.01 3.28 17.79 3.63 18.54 3.97 19.27 4.33 19.97 4.69
3210 16.75 3.52 17.57 3.90 18.34 4.29 19.08 4.67 19.78 5.06 — —
3540 17.26 4.09 18.07 4.50 18.84 4.93 19.57 5.35 — — — —
024
2830 16.01 2.88 16.85 3.22 17.64 3.56 18.39 3.91 19.12 4.26 — —
3300 16.67 3.57 17.50 3.96 18.28 4.36 19.03 4.75 19.73 5.15 — —
3780 17.35 4.39 18.17 4.82 18.95 5.27 19.68 5.72 — — — —
4250 18.11 5.37 18.88 5.83 19.63 6.31 — — — — — —
4720 18.96 6.58 19.67 7.05 — — — — — — — —
028
3540 14.57 3.97 14.95 4.41 15.67 5.07 16.50 5.59 — — — —
4130 14.76 3.99 15.51 4.57 16.36 5.46 17.00 6.04 — — — —
4720 15.49 4.92 16.15 5.37 16.78 5.88 17.42 6.50 — — — —
5310 16.26 6.15 16.91 6.61 17.51 7.08 18.10 7.58 — — — —
5900 17.04 7.61 17.68 8.11 18.28 8.62 — — — — — —
034
4250 14.68 4.00 15.38 4.49 16.12 5.14 17.00 6.15 — — — —
4960 15.51 5.20 16.17 5.63 16.80 6.09 17.41 6.61 — — — —
5660 16.35 6.72 17.01 7.21 17.64 7.69 18.23 8.18 — — — —
6370 17.24 8.54 17.87 9.10 — — — — — — — —
7080 18.22 10.70 — — — — — — — — — —
