Table 10C — High-Static Drive Data, 50 Hz — English
*It is possible to adjust drive so that fan speed exceeds maximum allowable. DO NOT
exceed 1200 rpm.
Table 10D — Standard Drive Data, 50 Hz — SI
UNIT
40RM
007
40RM
40RMQ
40RMS
008
40RMS
010
40RM
40RMQ
40RMS
012
40RM
40RMS
014
40RM
40RMQ
40RMS
016
40RM
40RMQ
40RMS
024
40RM
40RMQ
40RMS
028
40RM
40RMS
034
MOTOR DRIVE
Motor Pulley Pitch Diameter (in.)
3.4-4.4
3.4-4.4
3.4-4.4
4.0-5.0
3.4-4.4
4.0-5.0
4.0-5.0
4.3-5.3
4.3-5.3
Pulley Factory Setting
Full Turns Open
2.5
2.5
2.5
3.0
2.5
3.0
3.0
3.0
3.0
FAN DRIVE
Pulley Pitch Dia (in.)
6.0
5.5
5.5
5.5
6.0
7.0
6.4
8.0
8.6
Pulley Bore (in.)
1
1
1
1
1
7
/
16
1
7
/
16
1
7
/
16
1
15
/
16
1
15
/
16
Belt No. — Section
1—A
1—A
1—A
1—A
2—A
2—A
2—A
2—B
2—B
Belt Pitch (in.)
37.3
37.3
37.3
36.3
36.3
39.3
34.3
36.8
37.8
FAN SPEEDS (rpm)
Factory Setting
926
1010
1010
1166
926
916
1002
855
795
Range
808-
1045
881-
1140
881-
1140
1036-
1200*
808-
1045
814-
1018
891-
1113
766-
944
713-
878
Max Allowable Speed (rpm)
1200
1200
1200
1200
1200
1200
1200
1100
1100
Change per
1
/
2
Turn of
Moveable Motor Pulley
Flange
23.7
25.9
25.9
21.6
23.7
17.0
18.5
14.8
13.8
MAX FULL TURNS FROM
CLOSED POSITION
5
5
5
6
5
6
6
6
6
SHAFTS CENTER DISTANCE (in.)
10.44-
12.32
10.44-
12.32
10.44-
12.32
9.16-
10.99
9.16-
10.99
9.16-
10.99
8.16-
10.02
6.67-
9.43
6.67-
9.43
UNIT
40RM
007
40RM
40RMQ
40RMS
008
40RMS
010
40RM
40RMQ
40RMS
012
40RM
40RMS
014
40RM
40RMQ
40RMS
016
40RM
40RMQ
40RMS
024
40RM
40RMQ
40RMS
028
40RM
40RMS
034
MOTOR DRIVE
Motor Pulley Pitch Diameter (mm)
61.0
86.4
71.1
96.5
71.1-
96.5
86.4-
111.8
86.4-
111.8
86.4-
111.8
109.2
134.6
109.2-
134.6
109.2-
134.6
Pulley Factory Setting
Full Turns Open
2.5
2.5
2.5
2.5
2.5
2.5
3.0
3.0
3.0
FAN DRIVE
Pulley Pitch Dia (mm)
203
203
203
203
229
229
218
279
279
Pulley Bore (mm)
25.4
25.4
25.4
25.4
36.5
36.5
36.5
49.2
49.2
Belt No. — Section
1—A
1—A
1—A
1—A
1—A
1—A
1—B
2—B
2—B
Belt Pitch (mm)
998
998
998
1024
1074
1074
1062
1113
1113
FAN SPEEDS (r/s)
Factory Setting
8.6
9.8
9.8
11.6
10.3
10.3
13.3
10.4
10.4
Range
7.1-10.1
8.3-11.3
8.3-11.3
10.1-13.1
9.0-11.6
9.0-11.6
11.9-14.6
9.3-11.5
9.3-11.5
Max Allowable Speed (r/s)
20.0
20.0
20.0
20.0
20.0
20.0
20.0
18.3
18.3
Change per
1
/
2
Turn of
Moveable Motor Pulley
Flange
0.297
0.297
0.297
0.297
0.265
0.265
0.230
0.180
0.180
MAX FULL TURNS FROM
CLOSED POSITION
5
5
5
5
5
5
6
6
6
SHAFTS CENTER DISTANCE (mm)
265-313
265-313
265-313
265-313
265-313
265-313
232-279
169-240
169-240
