and S/PDIF (TV/digital audio-adapter cable supports
composite video and S/PDIF)
Mini PCI Type IIIA Mini PCI card slot
Modem RJ-11 support
Network adapter RJ-45 port
Communications
Modem:
Type v.92 56K MDC
Controller softmodem
Interface internal AC'97 bus
Network adapter 1 Gb Ethernet LAN on system board
Wireless internal Mini PCI Wi-Fi and Bluetooth® wireless
technology support
Video
Video type 128-bit hardware accelerated
Data bus PCI Express
Video controller NVIDIA Quadro FX Go1400 256 MB
Video memory 256 MB
LCD interface LVDS
TV support NTSC or PAL in S-video and composite modes
Audio
Audio type AC'97 (Soft Audio)
Audio controller SigmaTel STAC9751
Stereo conversion 20-bit (stereo digital-to-analog),
18-bit (stereo analog-to-digital)
Interfaces:
Internal PCI bus/AC'97
External microphone miniconnector, stereo
headphones/speakers miniconnector
Speaker two 4-ohm speakers
Internal speaker amplifier 2-W channel into 4 ohms
Volume controls keyboard shortcuts or program menus
Display
Type (active-matrix TFT) WXGA, WSXGA+, or WUXGA
Dimensions:
Height 222.5 mm max (8.7 inches)
Width 344.5 mm (13.56 inches)
Diagonal 391.16 mm (15.4 inches)
Resolutions:
WXGA 1280 x 800 max resolution
WSXGA+ 1680 x 1050 max resolution
WUXGA 1920 x 1200 max resolution
Refresh rate 60 Hz
Operating angle 0º (closed) to 180°
Viewing angles:
WXGA Horizontal 40/40°
WXGA Vertical 10/30°
WSXGA+ Horizontal 65/65°
WSXGA+ Vertical 50/50°
WUXGA Horizontal 65/65°
WUXGA Vertical 50/50°
Pixel pitch:
