Adding and Replacing Parts 217
NOTICE:
If only one hard drive is to be installed , it should be connected to the
SATA0 connector on the system board.
12 Ensure that all connectors are properly cabled and firmly seated.
13 Rotate the hard-drive carrier back into place (see "Rotating the Hard-Drive
Carrier Back into the Computer" on page 159).
14 Replace the computer cover (see "Replacing the Computer Cover" on
page 161).
NOTICE: To connect a network cable, first plug the cable into the network port or
device and then plug it into the computer.
15 Connect the computer and devices to electrical outlets, and turn them on.
See the documentation that came with the drive for instructions on
installing any software required for drive operation.
1 P3 power connector 2 SATA data cable
3 hard-drive power cable 4 hard drive
2
3
4
1
