Local and Remote Configuration xxx | xxx 69
Outlet 1 Status
Outlet 2
Status
Resulting Status
Locked-On On Powered On
Locked-On Locked-On Locked-On
Locked-On Off Partial Power
Locked-Off On Partial Power
Locked-Off Locked-Off Locked-Off
Locked-Off Off Powered Off
Locked-On Locked-Off Partial Power
Local Session Page on the Local Port
On the local port's Local Session page, when the target of the active session has
power outlets linked, three power controls are displayed on the page under the
Active session. The following figure illustrates the power controls displayed for
an active local port session for a target named Server2.
Figure 3.7: Local Session Page With Power Controls
