About Your Printer
Operator Panel
Protecting Your Printer
The following illustrations show the standard Dell™ 2130cn Color Laser Printer.
Provide enough room to open the printer tray, covers, and option. It is also important to allow space around the printer for proper ventilation.
Operator Panel
For details on the operator panel, see "Operator Panel" .
Protecting Your Printer
1 Operator Panel 6
Optional 250-Sheet Feeder
NOTE: Your printer allows for a maximum of 3 trays (standard 250-sheet tray, optional 250-sheet feeder, and single
sheet feeder).
2 Side Button 7 Standard 250-Sheet Tray
3
Side Cover (toner cartridges
inside)
8 Single Sheet Feeder
4 Belt Unit 9
Front Cover
NOTE: You can open the front cover by pushing the Side Button.
5 Duplexer (Sold separately)
