Dell 2130cn Color Laser Printer - Manual (Page 118)

Removing a Memory
1. Ensure that the printer is turned off.
2. Turn the screw on the control board cover in a counter-clockwise direction and open the cover.
3. Remove the control board cover.
4. Push the latches on both edges of the socket outward at the same time to raise the memory up.
5. Hold the memory and pull it out.
6. Install the control board cover.
NOTE: Take off the below edge of the control board cover by turning the control board cover on hinge in the above edge. Next, remove the control
board cover by pulling it from the printer.
NOTE: Insert the above hinge of the control board cover into the above slit on the printer. Next, insert the below hinge of the control board cover
into the below slit on the printer.
