3.

Completely remove the eight yellow ribbons from the PHD unit.



4.

Remove the rear protective cover from the PHD unit.



5.

Insert the PHD unit until the line on the handle aligns with the white line on the printer.



6.

Turn the four PHD lock levers 90 degrees clockwise to lock the PHD unit.



NOTE:

Do not remove the front protective cover at this moment.
