Dell LATITUDE C510 - Manual (Page 116)

Display
Type (active-matrix TFT) for C610
computers XGA; SXGA+
Type (active-matrix TFT) for C510
computers XGA
Dimensions:
Height 214.3 mm (8.4 inches)
Width 285.7 mm (11.3 inches)
Diagonal 357.1 mm (14.1 inches)
Maximum resolutions 1024 x 768 at 16.8 million colors
(XGA);
1400 x 1050 at 16.8 million colors
(SXGA+)
Response time (typical) 20-ms rise (maximum),
30-ms fall (maximum)
Refresh rate 60 Hz
Operating angle 0° (closed) to 180°
Viewing angles:
Horizontal ±40°
Vertical +10°/–30°
Pixel pitch 0.28 x 0.28 mm (XGA)
0.20 x 0.20 mm (SXGA+)
Power Consumption:
Panel with backlight (typical) 6.5 W (XGA)
7.0 W (SXGA+)
Controls brightness can be controlled
through keyboard shortcuts
Keyboard
Number of keys 87 (U.S. and Canada); 88 (Europe);
91 (Japan)
Key travel 2.7 mm ± 0.3 (0.11 inch ± 0.016
inch)
Key spacing 19.05 mm ± 0.3 mm (0.75 inch ±
0.012 inch)
Layout QWERTY/AZERTY/Kanji
