Installing System Components
85
Removing the Fan Assembly
CAUTION:
Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1 Open the system. See "Opening and Closing the System" on page 70.
2 Remove the system board shroud. See "Removing the System Board
Shroud" on page 72.
3 Disconnect the fan connectors on the system board FAN_MOD1 and
FAN_MOD2. See Figure 3-10.
4 While pulling the two release levers on the fan assembly, lift the fan
assembly off of the two securing posts and out of the chassis. See
Figure 3-10.
