Dell PowerEdge R300 User Manual
Page 79
Installing System Components
79
d
As you seat the hard drive into the hard-drive bay, ensure the carrier
latch contacts the carrier bracket and ensure that all latches are fully
engaged.
Figure 3-7.
Installing a SAS Hard Drive Into a SAS/SATAu Drive Carrier
1
screws (4)
2
drive carrier
3
hard drive
2
1
3
