108
Installing System Components
2 Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
3 Open the system. See "Opening the System" on page 71.
4 If applicable, disconnect the SAS cable connector on the expansion card.
5 Remove the system board shroud. See "Removing the System Board
Shroud" on page 72.
6 Position your thumb firmly over the socket-release lever and release the
lever from the locked position. Rotate the lever 90 degrees upward until
the processor is released from the socket. See Figure 3-20.
7 Gently lift the heat sink off of the processor and set the heat sink aside.
NOTICE:
The processor is held in its socket under strong pressure. Be aware that
the release lever can spring up suddenly if not firmly grasped.
