Installing System Components
81
Installing the Optical Drive
1 Align the optical-drive tray with its opening in the front panel. See
Figure 3-8.
2 Slide in the drive tray until the tray snaps into place.
3 Connect the optical-drive cable to the back of the drive tray.
4 If not already done, connect the power and interface cables from the
optical drive to the system board connectors.
a Connect the power cable to the CD_PWR connector on the SATA
ODD. See Figure 6-4 for the location of the connector and see
Figure 3-8 for the routing of the cable.
b Route the interface cable along the inside right-chassis side panel,
inserting the cable under each of the cable routing tabs. See
Figure 3-8.
c Connect the interface cable to the SATA_C connector on the system
board. See Figure 3-8 for the location of the connector.
5 Close the system. See "Closing the System" on page 71.
6 Replace the bezel. See "Replacing the Front Bezel" on page 70.
7 Reconnect your system and peripherals to their electrical outlets, and turn
on the system.
