68
Installing System Components
Figure 3-1. Inside the System
1 cooling fan 2 internal hard drives (2)
3 expansion-card riser 4 power supply bays (2)
5 cooling shroud 6 heat sink/processor
7 memory modules (8) 8 system cooling fans (4)
9 SAS backplane 10 hard drives (12)
5
4
8
9
10
7
1
3
6
2
