Page 69: Infrared

Speakers, Audio Connectors, and Consumer Infrared

Speakers, Audio Connectors, and

Consumer Infrared

Removing Speakers

CAUTION:

Before you begin any of the procedures in this section, follow the

safety instructions in the

Product Information Guide.

NOTICE:

To avoid electrostatic discharge, ground yourself by using a wrist

grounding strap or by periodically touching an unpainted metal surface (such as the

back panel) on the computer.

1 Follow the instructions in "Before You Begin" on page 9.
2 Remove any installed ExpressCards from the ExpressCard slot.
3 Remove any installed memory modules or Mini Cards (see "Memory" on

4 Remove the hard drive (see "Hard Drive" on page 15).
5 Remove the palm rest (see "Palm Rest" on page 49).
6 Remove the audio connector board from the system board by removing the

screw and the audio connector cable. See "Removing the Audio Connector

7 Remove the two speaker screws (one on each speaker) from the computer

base.

8 Disconnect the speaker connector from the system board.
9 Remove the two speakers by lifting them up.
