Dell XPS M1730 (M1730, Late 2007) - Manual (Page 41)

Display Assembly 41
Replacing the Display Bezel
1 Realign the display bezel over the display panel, and gently snap into place.
2 Replace the two screws securing the display bezel to the display assembly.
3 Replace the two rubber screw-covers/display bumpers around the screws.
Removing the Display Panel
1 Remove the display assembly (see "Removing the Display Assembly" on
page 37).
2 Remove the display bezel (see "Removing the Display Bezel" on page 40).
3 Remove the display cable from the routing channel.
4 Remove the camera cable connector.
5 Remove the twelve screws that secure the display panel brackets to the
display panel.
2
1
3
4
