Dell XPS M1730 (M1730, Late 2007) User Manual
Page 63
Processor Thermal-Cooling Assembly
63
NOTE:
The original pad can be reused if the original processor and heat sink are
reinstalled together. If either the processor or heat sink is replaced, use the thermal
pad provided in the kit to ensure that thermal conductivity is achieved.
NOTE:
This procedure assumes that you have already removed the processor
thermal-cooling assembly and are ready to replace it.
1 Peel the backing off the thermal cooling pad and adhere the pad to the
portion of the thermal-cooling assembly that covers the processor.
2 Place the assembly on the system board.
3 Tighten the five captive screws on the thermal-cooling assembly.
