GamePanel 47
11
GamePanel
Removing the GamePanel
CAUTION: Before working inside your computer, follow the safety instructions in
the Product Information Guide.
NOTICE: To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on the back of the computer).
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the hinge cover (see "Removing the Hinge Cover" on page 25).
3 Remove the keyboard (see "Removing the Keyboard" on page 27).
4 Disconnect the GamePanel connector from the system board.
5 Remove the two screws securing the GamePanel.
1 screws (2)
1
