Display Assembly 39
10 If applicable, remove the camera cable connector from the system board.
11 Remove the display assembly from the computer base by rotating it
towards you.
Replacing the Display Assembly
1 If applicable, replace the camera cable.
2 Reconnect the display power cable to the connector on the system board.
3 Reconnect the display graphics cable to the connector on the graphics
card.
4 Make note of the cable routing and carefully slide the Mini-Card antenna
cables through the computer base and into their routing guides.
5 Replace the four screws on the hinges.
6 Reconnect the mini card cables to the Mini Cards if applicable (see
"Wireless Mini Cards" on page 31).
1 display power connector 2 display graphics connector
2
1
